Normalization of Database: Principle, Goal, and Use

Here’s a revised version of your article with improved grammar while maintaining the original structure: Learn about database normalization, a crucial procedure in data collection that reduces redundancy and boosts integrity. Discover how to efficiently collapse tables to maximize your database work.Within the field of information technology, effective and structured data collection via various automated systems, such as CRM, is one of the key components in enhancing efficient business operations.



A system that can automatically process this data is not affected by inconsistent or erroneous data, nor by data redundancy.Effective data collection processes require sound data management procedures. One of the techniques used to achieve this goal is database normalization. Normalization of data serves the purpose of producing non-redundant and well-structured data that can be easily examined, analyzed, and modified in order to provide data that is accurate and consistent.



Most of us have probably encountered this concept, but we don’t fully understand what normalization is and how important it is in data handling. This article will discuss database normalization in detail, including its concepts, goals, and benefits that result from its application.

Definition of Database Normalization

Database normalization is the process of organizing data in a database to reduce redundancy and enhance data integrity. The processes involved in database normalization include cleaning or arranging data to create well-structured information in accordance with established standards. In the normalization process, tables in the database are arranged so that each table contains only information directly related to a specific entity.Normalization is carried out by breaking down large tables into smaller tables, thereby reducing data duplication and facilitating maintenance. This process also aims to ensure that the data stored in these tables can be easily accessed, modified, and updated without causing inconsistencies.The purposes of database normalization include:

  • Eliminating Data Redundancy
  • Reducing Data Complexity
  • Simplifying the data analysis and organization process

Stages of Database Normalization

In a database, there are several levels of normalization stages. The stages in data normalization generally consist of 1NF to 5NF.

1NF

First Normal Form (1NF): A table is said to be in the first normal form or 1NF if it meets the following criteria:

  • It does not have multi-value attributes (there are no repeating groups of data).
  • Each cell contains only one unique single value.

At this level, tables containing repeating elements are broken down into smaller tables.

NIM Name Address Postal Code Course Content SKS Value
1234 elin Ciganitri 40240 User Experience 4 85
1235 budi Buah Batu 40257 Accounting 4 86
1236 bagus Buah Batu 40257 Database 2 82
1237 ara Buah Batu 40257 Database 2 81
1238 cimut Buah Batu 40257 Programmer 3 80
1239 citra Cimahi 40260 Programmer 3 80

2NF

A table is in the second normal form if it meets the requirements of 1NF and all non-key attributes depend on the primary key. At this level, all attributes that are not directly related to the primary key are moved to another table. Here are some requirements that must be met for the 2NF stage in database normalization:

  • All attributes must depend on the primary key.
  • If partial dependency is found, then the attribute must be separated into another table and should be supported by a foreign key.

Eliminate partial dependence in the following way:

  1. Separate the student ID (NIM) into a new table, the Student Table, which contains information on Name, Faculty, and Study Program.
  2. Separate the course codes into a new table, the Course Table, which contains information about the Courses and Credits.
  3. The primary key is the Student ID (NIM) and the Course Code.
  4. The remaining attributes and the primary key become a new table, the Score Table.

Student Table

NIM Name Address Postal Code
1234 elin Ciganitri 40240
1235 budi Buah Batu 40257
1236 bagus Buah Batu 40257
1237 ara Buah batu 40257
1238 cimut Buah batu 40257
1239 citra Cimahi 40260

Course Table

Course Code Course SKS
M001 Usee Experience 4
M002 Accounting 4
M003 Database 2
M004 Programmer 3

Value Table

NIM Course Code Value
1234 M001 85
1235 M002 86
1236 M003 82
1237 M003 81
1238 M004 80
1239 M004 80

3NF

A table is in the third normal form when all non-key attributes that depend on other non-key attributes are moved to another table, ensuring that all non-key attributes depend directly on the primary key. Here are some requirements that must be met for the 3NF stage in database normalization:

  1. There is no transitive dependency (i.e., non-key attributes depend on other key attributes).
  2. Eliminate the following transitive dependency:
    • Separate the study programs and faculties into a new table, the Study Program Table, which contains information about the Study Program and Faculty. In this case, the non-key attribute is the Study Program, which will form the new table and become the Primary Key.

Student Table

NIM Name
1234 elin
1235 budi
1236 bagus
1237 ara
1238 cimut
1239 citra

Postal Code Table

Postal Code Address
40240 Ciganitri
40257 Buah Batu
40260 Cimahi

Tabel Mata Kuliah

NIM Course SKS
M001 Usee Experience 4
M002 Accounting 4
M003 Database 2
M004 Programmer 3

Tabel Nilai

NIM Course Code Value
1234 M001 85
1235 M002 86
1236 M003 82
1237 M003 81
1238 M004 80
1239 M004 80

BCNF

Boyce-Codd Normal Form (BCNF): The Boyce-Codd Normal Form is an enhancement of 3NF where a table must meet 3NF and every determinant is a super key. (superkey).

4NF

Fourth Normal Form (4NF): A table is in the fourth normal form if it meets BCNF and has no multi-valued dependencies. At this level, tables with multi-valued dependencies are broken down into smaller tables to eliminate anomalies.

5NF

Fifth Normal Form (5NF): The fifth normal form relates to join dependencies. A table is in the fifth normal form if it meets 4NF and all existing join dependencies have been resolved.

Also Read : Getting to Know Backlinks More Deeply: An Important Foundation of SEO

The Purpose of Database Normalization

There are several main objectives of database normalization that make it an important part of good database design:

Reducing Data Redundancy

One of the main goals of normalization is to reduce data duplication. By breaking down large tables into smaller tables, we can minimize unnecessary data repetition. This helps save storage space and improves data management efficiency.

Improving Data Integrity

Normalization helps maintain the consistency and accuracy of data. By organizing data into structured tables, the risk of data anomalies, such as unsynchronized or conflicting data, can be minimized.

Facilitating Data Maintenance

A normalized database is easier to maintain because the data is organized neatly and structured. When there are changes or updates to the data, corrections can be made more quickly and accurately without affecting the entire database.

Improving Query Performance

With efficiently organized data, the performance of queries or data requests can be improved. Normalization allows databases to retrieve and process data more quickly, especially when dealing with large amounts of data.

Testing Data Normality and Its Relation to Database Normalization

One term that is often associated with database normalization is the data normality test. The data normality test is a statistical procedure used to determine whether the distribution of data in a dataset follows a normal distribution. Although these terms are similar, the data normality test is different from database normalization. Normality tests are more commonly used in statistical analysis; this type of analysis can be assisted by statistical tools such as SPSS.

Meanwhile, database normalization focuses on organizing the data structure within database tables.Nevertheless, these two concepts are interconnected in data management. In some cases, well-normalized data in a database can facilitate the process of normality testing, as well-structured data is easier to analyze.



Also Read : How to Create Value Proposition Canvas



Benefits of Database Normalization

The application of database normalization in data management provides a number of significant benefits. Some of the main benefits of normalization are:

Space-Saving Storage

By reducing data redundancy, normalization helps save storage space. Unnecessary duplicated data will be eliminated, making the overall size of the database smaller.

Easier Data Management

A normalized database is easier to manage because the data is organized neatly and structured. Maintenance, updates, and deletions can be carried out more efficiently and with a lower risk of data inconsistency.

Improving the Speed and Efficiency of Queries

A normalized database allows queries or data requests to be executed more quickly and efficiently. This is especially important when dealing with large amounts of data, where query performance can affect data access speed.

Preventing Data Anomalies

Normalization helps prevent the occurrence of data anomalies, such as inconsistent or contradictory data. By organizing data into structured tables, the risk of data inconsistency can be reduced.

Facilitating Database Structure Changes

When there are changes in the database structure, such as the addition of new attributes or changes in relationships between tables, a normalized database is easier to adjust without disrupting the entire system.

Challenges in Database Normalization Implementation

Although database normalization has many benefits, there are also several challenges that need to be addressed in its implementation. One of the main challenges is the increased complexity that comes with higher levels of normalization. The higher the level of normalization, the more tables need to be managed, which can complicate the maintenance and management of the database.In addition, in some cases, overly strict normalization can lead to a decrease in query performance. This happens because data spread across multiple tables requires more complex joins or table merging to obtain the necessary information. Therefore, a balance between normalization and denormalization is necessary to ensure that database performance remains optimal.

Conclusion

Database normalization is one of the most important techniques in designing efficient and structured databases. By reducing data redundancy, enhancing integrity, and facilitating maintenance, normalization plays a significant role in ensuring that the data stored in the database can be managed effectively. Although implementing normalization can be complex and presents its own challenges, the benefits gained from its application far outweigh these difficulties, especially in long-term data management.Through normalization, databases can be designed better, making stored data more organized, easily accessible, and reliable. Thus, normalization becomes one of the crucial steps in supporting effective data management in various modern information systems.

Reference

Kidd, C. (2024, April 18). Data & database normalization explained: How to normalize data. Splunk. https://splunk.com/en_us/blog/learn/data-normalization.html

Gustiana, I. (n.d.). Normalisasi data [PowerPoint slides]. UNIKOM.
